Deconstruction of Gravitational Tidal Harmonics
Lord Kelvin identified 10 primary harmonic components resulting from lunar declination, solar distance, and shallow water friction.
Scotch Yoke Linkages and Amplitude Cranks
Each component was represented by an eccentric crank driving a scotch yoke with amplitude and phase set to match local harbor data.
Mechanical Fourier Summation across Ten Pulleys
A continuous flexible wire passing over ten alternating pulleys automatically added sinusoidal outputs to drive a pen across chart paper.
